Запчасти Case IH 8450 (022) - GEARBOX, S.N. CFH0015897 AND ON Driveline

700710131

TRANSFER BOX

Gearbox Complete - Primary

1шт.

1

700710827

SEAL

2шт.

2

700710828

OIL SEAL

Ring - Retaining

2шт.

3

700710815

PINION

Shaft - Pinion

1шт.

4

700710817

BEARING

- Cone, Tapered

3шт.

5

710350

BRACKET,69.037 mm OD x 15.875 mm

- Bearing

3шт.

6

712208

CUP

- Bearing

1шт.

7

712166

CONE

Bearing - Cone, Tapered

1шт.

8

700710823

GEAR

(20 Tooth)

1шт.

9

700710824

CASTING

(Thru Holes)

1шт.

10

746578

PLUG

1/4 NPT Solid Plug

1шт.

11

746586

PLUG

1/2 NPT Solid Plug

1шт.

12

701367

HEX SOC SCREW,3/8"-16 x 2 1/4"

3/8-16 x 2-1/4 HSHCS

9шт.

13

700710821

GEAR

(27 Tooth)

1шт.

14

700710820

SPACER

1шт.

15

700710816

CROSS SHAFT

Shaft - Cross

1шт.

16

700710825

CASTING

(Tapped Holes)

1шт.

17

700710819

DIPSTICK

1шт.

18

700710818

VALVE

Breather

1шт.

19

846642

BUSHING

1/2-1/8 NDT Reducer Bushing

1шт.
