Запчасти Bobcat 3400XL BODY, SEAT & BASE (Bucket Seat) (S/N AJNW20001 & Above) MAIN FRAME

Схема запчастей Bobcat 3400XL - BODY, SEAT & BASE (Bucket Seat) (S/N AJNW20001 & Above) MAIN FRAME

Артикул

Название

Примечание

Количество

1

7018899

BOLT

2

7023379

SEAT, BACK GUNMETAL set of 2 cushions

3

7023380

SEAT, BOTTOM GUNMETAL W/Ref. 11, 12 & 15

4

7016406

INSULATOR, FOIL, SEAT

5

7016804

BASE, CAB SEAT

6

7016413

GROMMET

7

7025298

SEATBELT, 3PT W/Ref. 10 & 16 - Was 7023117 - A

8

7016334

COVER, SEAT BACK, CENTER, BLK

9

7016091

BOLT

10

7016512

NUT

11

7016319

CONSOLE, SEAT, BLK

12

7016650

SCREW

13

7016805

BASE, CAB SEAT FRONT, BLK

14

7016531

PAD, REAR, SEAT BASE

15

7018902

RIVET

16

7020704

BOLT

17

7023381

COVER, BACK SEAT BLACK Was 7023410 - D

18

7024106

WASHER, RUBBER

Выбрано товаров: 18
