Запчасти Bobcat TR35160 STABILIZERS UNDERCARRIAGE

1

7020044

BUSHING

2

7014568

NUT, RING

3

7020125

NIPPLE, GREASE

4

7014556

SCREW

5

7019749

WASHER

6

7020152

PLATE, RH

7

7020174

ARM, LH

8

7014562

NUT

9

7020031

PIN

10

7018210

SCREW

11

7019770

STABILIZER, RH

12

7020182

WASHER

13

7020034

PIN

14

7018289

SCREW

15

7020032

PIN

16

7019769

STABILIZER, LH

17

7020153

PLATE, LH

18

7020180

SPACER

19

7020175

ARM, RH
