Запчасти Bobcat T40170 STABILIZERS & FRAME LEVEL CYLINDER INSTALLATION HYDRAULIC SYSTEM

1

6909143

Shoe

2

7213174

PIN Was 84237.7 - A

3

7213175

WASHER Was 100454-05T - A

4

1CM1630

BOLT Was 10882.9 - A

5

6909142

Arm

6

01782.2

Grease nipple

7

7213172

PIN Was 88597.0 - A

8

1CM1090

BOLT Was 12597.1 - A

9

100345-09A

NUT

10

6914550

RAM See Illustration STABILIZER CYLINDER/ SPC003027

11

90719.6

Elbow union

12

70862.8

Hose

12

6935717

HOSE, HYD

13

92650.1

Hose

13

6935718

HOSE, HYD

14

100370-29P

ELBOW PIECE

15

77912.4

Adapter

16

88808.1

Cylinder assy See Illustration FRAME LEVEL CYLINDER/ SPC003025

17

7213173

PIN Was 84177.5 - A

18

1CM1090

BOLT Was 12597.1 - A

19

100345-09A

NUT

20

01578.4

Screw

21

92652.7

Protector

22

000350-20Q

WASHER

23

01681.6

Nut Was 51851.4 - B

24

4CM825

BOLT Was 01597.4 - B

25

11463.7

Washer

26

000350-02V

WASHER

27

92323.5

Hose

27

6935891

HOSE, HYD

28

65485.5

Hose

29

80977.2

HOSE Was 65485.5

30

92323.5

Hose

31

98354.4

Selector valve See Illustration STABILIZER SELECTOR VALVES/ SPC003030
