Запчасти Bobcat T40140 PISTON & CRANKSHAFT POWER UNIT

1

7022484

KIT, CRANKSHAFT Ref. 2-6

2

CRANKSHAFT NLA - Order Ref. 1

3

6912021

MAIN BEARING KIT Was 7017230 - B,D

3

7022485

KIT, MAIN BEARING 0,25 mm (0.001'')

3

7022486

KIT, MAIN BEARING 0,50 mm (0.02'')

3

7022487

KIT, MAIN BEARING 0,75 mm (0.03'')

4

7023825

BEARING ROD Was 7022488 - A

5

6662035

WASHER Was 7017277 - A

5

3725400

WASHER Was 6912054 - A

6

6668230

WASHER Was 7017278 - A

6

3725402

WASHER Was 6912055 - A

7

6912046

CRANKSHAFT GEAR Was 7017232 - A

8

7017233

KEY, WOODRUFF

9

6924923

PISTON AND RING KIT Ref. 10-13

10

PISTON NLA - Order Ref. 9

11

PIN, PISTON NLA - Order Ref. 9

12

6924925

PISTON RING KIT Was 7017234 - A

13

6670886

RETAINER Was 7017279 - A

14

7022489

KIT, CONNECTING ROD grade R (red) - Ref.15-17

14

7022490

KIT, CONNECTION ROD grade O (orange)

14

7022491

KIT, CONNECTING ROD grade W (white)

14

7022492

KIT, CONNECTING ROD grade G (green)

14

7022493

KIT, CONNECTING ROD grade P (purple)

14

7022494

KIT, CONNECTING ROD grade B (blue)

15

ROD, CONNECTING NLA - Order Ref. 14

16

7017235

SMALL END BUSHING

17

7022495

BOLT
