Запчасти Bobcat T40140 PARKING BRAKE HYDRAULIC INSTALLATION HYDRAULIC SYSTEM

1

LEVER ASSY See Illustration PARKING BRAKE LEVER/ SPC001021 NAP Was 6909330

1

6915524

CONTROL, BRAKE HAND See Illustration PARKING BRAKE LEVER/ SPC001022

2

10167.5

Screw

3

94574.1

Washer

4

100345-06W

NUT

5

90289.0

Union

6

96567.3

Union

7

97663.9

Hose

8

96776.0

Hose Was 82421.9

9

92991.9

Hose

10

62849.5

T- union

11

90191.8

Tube

12

89475.8

Tube

13

100375-71D

UNION
