Запчасти Bobcat AL440 QUICK MOUNT HITCH CYLINDER HYDRAULIC INSTALLATION

Схема запчастей Bobcat AL440 - QUICK MOUNT HITCH CYLINDER HYDRAULIC INSTALLATION

Артикул

Название

Примечание

Количество

1

6502116100

HYDRAULIC CYLINDER Includes Ref. 2 to 8

2

0502116104

CYLINDER BARREL

3

6502116011

PISTON ROD Includes Ref. 9 to 11

4

1634935363

PISTON SEAL

5

0502116117

PIERCING BUSHING

6

1965956565

ROD SEAL

7

1970956867

O-RING

8

5060501050

ROAD SEAL

9

6502052720

FITTING Secure With LOCKTITE 242

10

5064320210

SPRING

11

1516638236

STEEL BALL

12

1976999236

SEAL KIT Includesd Ref. 4 + 6 to 8

13

MCS001035A

GLUE

Выбрано товаров: 13
