Запчасти Bobcat PRESSURE WASHER PUMP HIGH PRESSURE PUMP

1

MM27-8884

SHCS-GR12.9 M8-1.25PX16MM BLK

2

MM46-0713

PUMP-SHAFT COVER 0 ELECTRIC

3

MM26-0194

SEAL - OIL

4

MM25-0397

O-RING 72.75 X 1.78MM

5

MM48-0062

BEARING - TAPERED ROLLER

6

MM27-8886

HSSS - M6-1.00P X 6 MM UNI5923

7

MM46-0959

Crankshaft (After Serial #28511)

7

MM46-0734

PUMP - CRANKSHAFT

8

MM39-0102

PLUG BRASS

9

MM25-0325

O-RING 14 X 1.78MM

10

MM39-0086

PLUG - BRASS

11

MM27-8885

HSHCS-TCEI GR8.8 M5-0.8PX16MM

12

MM46-0719

PUMP - COVER CRANKCASE

13

MM25-0370

O-RING 20.24 X 2.62MM

14

MM46-0670

OIL SIGHT GLASS

15

MM46-0824

PUMP - REFLECTOR - OIL

16

MM46-0671

SPRING RETAINER-OIL SIGHT GLAS

17

MM25-0398

O-RING 107.62 X 2.62MM

18

MM46-0697

PUMP-CONNECTING ROD BRONZE

18

MM46-0922

PUMP-CONNECTING ROD BRONZE

19

MM46-0698

PUMP - PISTON PIN

20

MM46-0699

PUMP - PLUNGER ROD

21

MM46-0700

PUMP-SLINGER WASHER

22

MM25-0404

BACKUP RING 8 X 1MM

23

MM25-0382

O-RING 7.66 X 1.78MM

24

MM46-0701

PUMP - PISTON CERAMIC

25

MM26-0191

SEAL-WASHER/GASKET

26

MM30-6020

NUT - M8-1.25P X 15MM

27

MM39-0090

OIL DIPSTICK

28

MM46-0703

PUMP-BEARING CAP/SUPPORT

29

MM46-0704

Shim (Quanity Varies 1-3)

29

MM46-0705

Shim (Quanity Varies 1-3)

30

MM25-0380

O-RING 60 X 2.62MM

31

MM48-0061

BEARING - TAPERED ROLLER

31

MM48-0072

BEARING - TAPERED ROLLER

32

MM46-0811

PUMP-CRANKCASE XR NEW STYLE

33

MM46-0931

OIL SEAL

34

MM25-0384

O-RING 31.47 X 1.78MM

35

LOW PRESSURE SEAL NLA - Order Ref. 55

36

MM46-0708

PUMP - PACKING RETAINER

37

V-PACKING NLA - Order Ref. 55

38

SUPPORT RING NLA - Order Ref. 56

39

MM25-0372

O-RING 17.5 X 2MM

40

MM39-0088

PLUG - BRASS

41

MM39-0086

PLUG - BRASS

42

MM46-0711

PUMP - MANIFOLD - BRASS

43

MM39-0095

CAP - VALVE - BRASS

44

MM25-0160

O-RING 17.86 X 2.62MM

45

SINGLE VALVE ASSEMBLY NLA - Ref. 46-50 - Order Ref. 57

46

MM25-0386

O-RING 15.54 X 2.62MM

47

VALVE SEAT NLA - Order Ref. 57

48

VALVE PLATE NLA - Order Ref. 57

49

VALVE SPRING NLA - Order Ref. 57

50

VALVE CAGE NLA - Order Ref. 58

51

MM39-0096

PLUG - BRASS

52

MM25-0387

O-RING 10.82 X 1.78MM

53

MM27-8440

HSHCS - GR8.8 M8-1.25P X 70MM

54

MM29-0154

LOCKWASHER-ZI M8 SERR. CURVE

55

MM70-0177

KIT - PACKING (3) each of Ref. 34, 35 & 37

56

MM70-0178

KIT - SUPPORT RINGS (3) of Ref. 38

57

MM70-0179

KIT - VALVES (6) each of Ref. 46-50

58

MM70-0337

KIT, OIL SEAL Ref. 3, 4, 17, 30 & 33

59

MM70-0352

18MM PISTON KIT (3) each of Ref. 21-26
