Запчасти Bobcat PRESSURE WASHER PUMP ASSEMBLY PUMP

1

MM39-0018

PLUG/HEX

2

MM28-1002

WASHER - M22 X M17.2 X 1.5MM

3

MM39-0019

PLUG/HEX

4

MM28-1038

WASHER-ALUM M27 X M21 X 1.5MM

5

VALVE ASSEMBLY NLA - Order Ref. 55

6

MM25-0012

O-RING 20.69 X 2.62MM

7

MM46-0889

CAP VALVE

8

MM27-8185

HSHCS - M8-1.25P X 70MM

9

MM28-1039

WASHER-ZI M15 X M8 X 1.5MM

10

MM46-0890

Manifold

11

O-RING NLA - Order Ref. 55

12

VALVE SEAT NLA - Order Ref. 55

13

VALVE PLATE NLA - Order Ref. 55

14

VALVE SPRING NLA - Order Ref. 55

15

VALVE CAGE NLA - Order Ref. 55

16

HIGH PRESSURE HEAD RING NLA - Order Ref. 55

17

HIGH PRESSURE V-PACKING NLA - Order Ref. 56

18

V-PACKING SUPPORT NLA - Order Ref. 55

19

MM46-0659

INTERMEDIATE RETAINER-20MM

20

MM46-0886

LOW PRESSURE SEAL

21

MM46-0887

LOW PRESSURE SEAL RETAINER

22

MM25-0015

O-RING 1-3/8 X 1-1/2

23

MM26-0047

SEAL - OIL

24

MM9-0029

BUSHING

25

MM27-8431

HSHCS - M8-1.25P X 16MM

26

MM46-0336

CRANKCASE COVER CLOSED

27

MM25-0013

O-RING 2-11/16 X 2-7/8

28

MM48-0012

BEARING TAPERED ROLLER

29

MM46-0292

OBSOLETE WHEN GONE

30

MM46-0144

DIPSTICK 3-1/8LG

31

MM46-0069

NUT/PISTON

32

MM28-0400

WASHER-BRASS 7/32 X 3/8 X .02

33

MM25-0014

O-RING 7/16 X 9/16

34

MM46-0109

ANTI EXTRUSION RING

35

MM46-0052

PLUNGER CERAM 14X20X50LG

36

MM46-0146

SLINGER WASHER

37

MM46-0056

PISTON GUIDE

38

MM46-0051

CONNECTING ROD

39

MM29-0154

LOCKWASHER-ZI M8 SERR. CURVE

40

MM27-8435

HSHCS - M8-1.25P X 35MM

41

MM25-0339

O-RING

42

MM46-0295

CRANKCASE COVER

43

MM27-8404

HSHCS - M6-1.0P X 30MM

44

MM39-0017

PLUG/HEX

45

MM46-0114

INDICATOR - OIL LEVEL

46

MM43-0032

PIN/CONNECTING ROD

47

MM46-0103

RETAINING RING

48

MM46-0050

CRANKSHAFT

49

MM43-0048

PUMP KEY 7MM X 8MM X 35MM

50

MM26-0049

SEAL/OIL

51

MM46-0113

SHIM

52

MM46-0296

CRANKCASE COVER

53

MM29-0055

LOCKWASHER-ZI M10 TYPE A

54

MM27-8471

HSHCS-ZI GR8.8 M10-1.5P X 18MM

55

MM70-0009

KIT - VALVE (6) each of Ref. 5 & 11-15

56

MM70-0030

KIT - HEAD RING (3) of Ref. 16

57

MM70-0299

KIT - V-PACKING (3) each of Ref. 17, 18 & 20

58

MM70-0148

KIT-INTERMEDIATE RETAINER-20MM (3) each of Ref. 18 & 19

59

MM70-0298

KIT - LOW PRESSURE ASSEMBLY (3) each of Ref. 20-22

60

MM70-0300

KIT - V-PACKING ASSEMBLY Ref. 16-22
