Запчасти Bobcat PRESSURE WASHER FUEL TANK EQUIPMENT

1

DECAL NLA - Caution: Risk of Fire - Order Ref. 11

2

MM12-0126

FUEL TANK/10 GALLON/GREEN

3

MM12-0033

CAP FUEL VENTED 2-1/4'' BUTTRES

4

MM23-0408

BULKHEAD FITTING

5

MM25-0427

O-RING 1/8 X .734

6

MM23-0409

NUT

7

MM23-0247

1/4MNPT X 1/4 FLARE

8

MM33-0352

FUEL PICK-UP

9

MM23-0237

ELBOW 1/4'' FLARE X 1/4 MNPT 90

10

MM850-0290

Fuel Tank Assembly (Includes 1-9) Ref. 1-9

11

MM34-9012

DECAL SET - HSE Ref. 1
