Запчасти Bobcat PRESSURE WASHER PUMP ASSEMBLY PUMP

1

MM46-0221

CRANKCASE

2

MM39-0018

PLUG/HEX

3

MM25-0052

O-RING 9/16 X 3/4

4

MM46-0229

DRIP FAN

5

MM26-0111

OIL SEAL

6

MM39-0017

PLUG/HEX

7

MM46-0163

MANIFOLD - PUMP - BRASS

8

MM29-0153

LOCKWASHER-ZI M6 SERR. CURVE

9

MM27-8406

HSHCS - M6-1.0P X 40MM

10

O-RING NLA - Order Ref. 49

11

VALVE SEAT NLA - Order Ref. 49

12

VALVE PLATE NLA - Order Ref. 49

13

VALVE SPRING NLA - Order Ref. 49

14

VALVE CAGE NLA - Order Ref. 49

15

MM25-0012

O-RING 20.69 X 2.62MM

16

MM39-0035

VALVE PLUG

17

VALVE ASSEMBLY NLA - Order Ref. 49

18

HEAD RING NLA - Order Ref. 50

19

V-PACKING NLA - Order Ref. 50

20

MM46-0158

PACKING RETAINER - 15MM

21

MM25-0141

O-RING 25.12 X 1.78MM

22

MM25-0128

O-RING 15.08 X 2.62MM

23

MM46-0114

INDICATOR - OIL LEVEL

24

MM48-0019

BEARING NEEDLE

25

MM46-0143

DIPSTICK

26

MM46-0168

NUT

27

MM46-0166

WASHER - COPPER GASKET

28

MM46-0148

PLUNGER

29

MM25-0045

O-RING 7/32 X 11/32

30

MM25-0143

RING ANTI-EXTRUSION

31

MM46-0167

WASHER - SLINGER COPPER

32

MM43-0044

PIN CONNECTING ROD

33

MM46-0151

CRANKCASE COVER

34

MM27-8409

SHCS-ZI GR8.8 M6-1.0P X 18MM

35

MM25-0332

COVER O-RING

36

MM46-0152

CONNECTING ROD

37

MM46-0149

PISTON GUIDE

38

MM27-0118

HHSC-ZI GR5 3/8-16 X 1-1/4

39

MM29-0155

LOCKWASHER-ZI M10 SERR. CURVE

40

MM38-0032

FLANGE - PUMP - ELECTRIC

41

MM29-0153

LOCKWASHER-ZI M6 SERR. CURVE

42

MM27-8409

SHCS-ZI GR8.8 M6-1.0P X 18MM

43

MM46-0087

SPACER - BEARING

44

MM25-0060

O-RING 55.56 X 3.53MM

45

MM26-0126

SEAL - OIL

46

MM46-0245

RING SNAP

47

MM48-0024

BEARING - BALL

48

MM46-0277

CRANKSHAFT

49

MM70-0009

KIT - VALVE (3) each of Ref. 10-14 & 17

50

MM70-0024

KIT - PACKING (3) each of Ref. 18, 19, 21 & 22

51

MM70-0023

KIT - PACKING - W/BRASS Ref. 18-22
