Запчасти Bobcat PRESSURE WASHER GUN/WAND ASSEMBLY EQUIPMENT

1

MM16-0367

GUN BODY right side

2

MM16-0368

GIN BODY (LEFT SIDE) left side

3

MM27-8862

SCREW

4

MM23-0384

ADAPTER

5

PIPE NLA - Order Ref. 18

6

MM16-0370

BRASS BODY INLET

7

MM49-0141

SPRING

8

MM25-0363

O-RING

9

MM25-0416

BACK-UP RING

10

MM16-0371

VALVE

11

MM16-0372

TRIGGER LOCK

12

MM16-0373

TRIGGER

13

MM26-0238

SEAL RUBBER

14

MM16-0374

BRASS BODY OUTLET

15

MM16-0375

GRIPPING AREA (PLASTIC)

16

MM16-0376

PIPE

17

MM16-0377

SCREW CONNECT COUPLING

18

MM70-0288

INLET KIT (INCLUDES 4-6) Ref. 4-6

19

MM70-0289

SHUTTER VALVE KIT (INCLUDES 7-10) Ref. 7-10

20

MM16-0364

GUN & WAND AL9 3/8 FNPT INLET Ref. 1-17
