Запчасти Bobcat T-Series DECALS (Inside) ACCESSORIES & OPTIONS

1

6986649

KIT, DECAL T320 - Except where noted, includes decals from this ILL. (B26770) & ILL. B27334

1

7145253AR

KIT, TRANSLATION Argentina

1

KIT, TRANSLATION NLA - Brazil - Was 7145253BR - A

1

7145252AR

KIT, DECAL Argentina

1

7145252BR

KIT, DECAL Brazil

1

7145252JP

KIT, TRANSLATION Japan

1

7163310AR

KIT, DECAL Argentina

1

7163310BR

KIT, DECAL Brazil

1

7163310JP

KIT, DECAL Japan

2

6707852

DECAL, EXIT emergency

3

6718579

DECAL heater control - not in kit

4

6726303

DECAL, OPERATION removeable rear window

5

6733996

DECAL, WARNING engine coolant - 14 psi

6

6725370

DECAL 3-pt seat belt - not in kit

7

6565200

DECAL, FILTER

8

6727926

DECAL, OPERATION hand & foot controls - not in kit

9

6726423

DECAL, WARNING check before lifting

10

7117407

DECAL, FUSE inside fuse cover - 51 x 178 mm (2 x 7'')

10

7159779

DECAL fuse relay - 51 x 178 mm (2 x 7'')

11

7177806

DECAL, CAPACITY LOAD load cap. - Was 7170649 - A

12

6728540

DECAL, WARNING

13

6809511

DECAL, DANGER hose & tube

14

6734534

DECAL, SERVICE service checklist & schedule

15

6737248

DECAL, WARNING selectable joystick control

16

7120602

DECAL high flow hydraulics - not in kit

17

6735140

DECAL, THROTTLE

18

DECAL, SAFETY NLA - door sensor - Was 7110316 - A

19

7131520

DECAL warning - selectable joystick control

20

7131521

DECAL seat & seat bar operation - selectable joystick control

21

6986652

OHB, W WIRE ROPE - operation & maintenance - W/wire rope - not in kit - Was 6902808 - B,D

21

6558309

WIRE ROPE bulk - sold per foot

21

6558310

SLEEVE wire rope

22

6553976

SAFETY TREAD 127 x 203 mm (5 x 8'')

23

6555341

SAFETY TREAD 3'' x 12''

24

7108222

SAFETY TREAD 22.5'' (571,5 mm) wide irregular shape

25

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

26

6708929

DECAL, COOLANT propylene glycol

27

6718397

DECAL, WARNING no riders

28

6737189

DECAL, WARNING backup alarm
