Артикул
Название
Примечание
Количество
1
VALVE, CONTROL See BTI368 - NLA - valve is minus all fittings, relief valves, anti-cavitation valves, solenoid coils & solenoid spools - remove & use existing parts from old valve or order new parts a
2
VALVE, BICS See Illustration BICS CONTROL VALVE/ PE1730 - NLA - Was 6814269 - A
3
6589564
RETAINER
4
6587763
BOOT
5
6589565
BUSHING
6
99K6
O RING
7
SPOOL NLA - lift - # 1 or Red - Order 7108251 - Was 6677660 - A
7
SPOOL NLA - lift - # 2 or Green - Order 7108251 - Was 6677661 - A
7
7108251
SPOOL, LIFT Was 7101151 - A
8
SPOOL NLA - tilt - # 1 or Red - Order 7108242 - Was 6677662 - A
8
SPOOL NLA - tilt - # 2 or Green - Order 7108242 - Was 6677663 - A
8
7108242
SPOOL, TILT
9
6588074
SPOOL auxiliary
10
BODY NSS - valve
11
6592115
SEAT load check
12
6592117
SPRING, LOAD CHECK
13
79K8
O RING 10
14
6592116
NUT load check - W/Ref. 13
15
6667549
VALVE anti-cavity check - W/Ref. 16-18
17
80K14
BACK-UP WASHER Was 73K000014B - B
18
6677106
O-RING back-up washer not required
19
6679757
VALVE port relief - W/Ref. 16-18 - 4000 PSI
20
7219324
VALVE, RELIEF W/ O-rings - pressure to be set in field - Was 6686360 - A
21
58K017
O-RING 10
22
6665569
WASHER back-up
23
25K20016
O RING 10
24
6665570
RING glide
25
6595663
BUSHING
26
7211397
WASHER, SPRING Was 6587523 - A
27
6587580
SPRING
28
6592100
COLLAR
30
95K12
O-RING
31
90K8
PLUG W/Ref. 30 - socket head - Was 90KV00008B - A
32
O-RING NSS - Order Ref. 60 - kit
33
O-RING NSS - Order Ref. 60 - kit
34
79K6
O RING 10
35
79K7
O RING 10
36
54K20002
O'RING 10
37
6803092
BONNET .625 flange
38
6681933
CHECK VALVE 3000 PSI - W/screen - W/Ref. 34
39
7101345
BONNET, DETENT HYD VALVE Was 6587633 - A
40
30G416
BOLT
41
6592109
ADAPTER
43
6588781
END CAP .87'' thick
44
58K124
O RING 10
45
6596332
SPRING
46
7108780
SLEEVE Was 6595951 - A
47
6592720
PLUG W/Ref. 16-18
48
1K127
O-RING 10 Was 93K127 - A
49
6817552
CROSS W/Ref. 6 - Was 6805241 - A
50
6734058
TUBELINE
51
29G412
BOLT
52
29G416
BOLT 1'' long
53
6662848
CAP
54
6805696
TEE W/Ref. 6
54
97K6
O RING flared end
55
6806496
TUBELINE
56
25K20012
O RING 10
57
6677201
SOLENOID W/Ref. 58 & 59
58
6676249
STEM, VALVE SOLENOID
58
6586459
SEAL KIT
59
6717706
COIL, 10 VOLT W/Ref. 61 - 10 volt
60
6678552
VALVE port relief & anti-cav. - W/Ref. 16, 32 & 33 - 3500 PSI - use in tilt cylinder base end port
60
6673904
SEAL KIT W/Ref. 16, 32 & 33
62
6595131
SPRING .72'' OD
63
6805651
BLOCK aux
65
95K6
O'RING
66
6806561
PLUG W/Ref. 35 & 56
67
6814247
FITTING
68
55K204
O RING 10
69
36K5
CAP
70
54K20028
O RING 10
71
6816250
KIT, SEAL one spool - Ref. 4, 36, 42, 48, 51 & 52
71
6816253
KIT, SEAL complete - Ref. 4, 6, 13, 16-18, 21-24, 34, 35, 42, 44, 48, 51, 52 & 68 - also Order 6816250
71
6661328
SEAL KIT main relief - Ref. 21-24
71
6809425
SEAL KIT Ref. 13 & 16-18
71
6586459
SEAL KIT W/Ref. 16, 32 & 33
Выбрано товаров: 82
