Запчасти Bobcat T-Series MANUAL LIFT RELEASE SYSTEM (S/N 518911353, 516811036, 517511032 & Below) HYDRAULIC SYSTEM

Схема запчастей Bobcat T-Series - MANUAL LIFT RELEASE SYSTEM (S/N 518911353, 516811036, 517511032 & Below) HYDRAULIC SYSTEM

Артикул

Название

Примечание

Количество

1

7230495

VALVE, LIFT MANUAL See Illustration MANUAL LIFT RELEASE VALVE/ PE1547 - manual lift release - Was 6667844 - A

2

6707101

SEAL neoprene

3

7D4

NUT for 6667874

4

6737524

KNOB red square - Was 6668913 - A

5

6718881

BRACKET Was 6716253 - D

6

35C624

BOLT Was 35C000620B - B

7

83D6

NUT 5

8

17C428

BOLT

9

83D4

NUT 10

10

ADAPTER NLA - W/Ref. 13 - Tapered Boss Face - Was 15KV-5 - A

10

97K6

O RING flared end

10

15KB0606

FITTING, HYD CONNECTOR W/Ref. 13 - flat boss face

11

6817553

CROSS W/Ref. 13 - flat boss face - Was 6805241 - A

11

21KB0606

FTG HYD STRAIGHT TEE W/Ref. 13 - tapered boss face - Was 21KV00005B - A

12

36K5

CAP

13

79K6

O RING 10 flat boss face

13

99K6

O RING tapered boss face

14

6714856

HOSE

14

6729602

HOSE 21'' (533 mm) long - available only as an assembly W/two danger decals installed

14

6809511

DECAL, DANGER

15

6719555

HOSE

15

6725430

HOSE

16

6706790

HOSE

17

21KB0606

FTG HYD STRAIGHT TEE W/Ref. 13 - flat boss face - Was 21KV00005B - A

17

97K6

O RING flared end

17

21KB0808

FTG HYD STRAIGHT TEE W/Ref. 23 - flat boss face - Was 21KV00006B - A

17

97K8

O-RING flared end

18

CONTROL VALVE

19

SHIELD NLA - 21'' (533mm) long - Order Ref. 20

20

6650108

HOSE COVER bulk - 1.35'' (33,5mm) I.D. - Sold Per foot

21

35C616

BOLT 5

22

6718660

TEE

22

97K6

O RING flared end

23

99K8

O-RING

24

6563922

SNUBBER 1/8 in. Pipe Thread

24

6718948

SNUBBER .375 in. UNF Thread

25

6672766

CHECK VALVE

26

6731897

HOSE

27

19KB0808

Fitting Hydraulic Branch Tee W/Ref. 23 - Was 19KN00006B - A

27

97K8

O-RING Flared End

28

15KB0808

FITTING, HYD CONNECTOR W/Ref. 23 - Was 15KN00006B - A

28

97K8

O-RING Flared End

29

6718031

TEE

Выбрано товаров: 43
