1
6669460
HOSE
2
6669461
HOSE
3
6729780
TUBELINE
4
6719354
TUBELINE
5
10C528
BOLT
6
6718754
CLAMP
7
36K7
FITTING
8
85D5
NUT 5
9
6727810
HOSE
10
99K12
O RING tapered boss face
10
79K12
O RING 10 flat boss face
11
6717933
CLAMP
12
CYLINDER See Illustration LIFT CYLINDER/ TS1451 - lift
13
CYLINDER See Illustration TILT CYLINDER/ MS1988 - tilt
14
6578773
HOSE
15
6578774
HOSE
16
6718971
TUBE
17
6718167
TUBE
18
TEE NLA - W/Ref. 29 - Tapered boss face - Was 6715187 - A
18
97K8
O-RING flared end
18
21KB0810
FITTING, HYD TEE W/Ref. 29 - Flat boss face
19
83D5
NUT 5
20
21KB1010
FITTING, HYD TEE W/Ref. 29 - Was 21KN00007B - A
20
97K10
O-RING 10 flared end
21
84G3728
BOLT
22
6717378
BOLT
23
15KB1010
FITTING, HYD CONNECTOR W/Ref. 29 - tapered boss face - Was 15KV00007B - A
23
97K10
O-RING 10 flared end
24
6718946
TUBE
25
6718947
TUBE
26
12H15
FITTING, GREASE 5
27
872229
WASHER
28
6701892
CLAMP
29
99K10
O'RING tapered boss face
29
79K10
O RING 10 flat boss face
30
6669674
HOSE
31
6718161
TUBELINE
32
6718162
TUBELINE
33
11H15
GREASE FITTING
34
59D8
NUT 5
35
85D6
NUT, 5
36
17C616
BOLT 5
37
6727750
BRACKET Was 6710301 - A
38
17C528
BOLT
39
VALVE See Illustration HYDRAULIC CONTROL VALVE/ MS1614 - control
40
6701893
CLAMP
41
6553709
WASHER rectangular
42
10H25
FITTING, GREASE 5
43
6718726
MOUNT
44
VALVE See Illustration BUCKET POSITIONING VALVE/ MS1943 - Bucket positioning
45
6718831
TUBELINE tilt
46
6718832
TUBELINE tilt
47
6718877
TUBELINE lift
48
17C632
BOLT 5
49
17C540
BOLT
50
83D6
NUT 5
51
17KB1010
FITTING, HYD ELBOW W/Ref. 29 - Was 17KV00007B - A
51
97K10
O-RING 10 flared end
52
15KB1212
FITTING, HYD CONNECTOR W/Ref. 10 - tapered boss face - Was 15KN00008B - A
52
97K12
O'RING flared end
52
15KB1212
FITTING, HYD CONNECTOR W/Ref. 53 - flat boss face
