Запчасти Bobcat T-Series HIGH FLOW HYDRAULICS (S/N 5193 11761 & Bel, 5194 11111 & Bel) HIGH FLOW HYDRAULICS

1

6667806

COUPLER male

1

6669659

O-RING

2

6726479

ADAPTER W/Ref. 25 - tapered boss face - Was 6711628 - A

2

97K6

O RING flared end

3

6711913

BRACKET

4

86F5

NUT

5

6718136

TUBE

6

7114121

HOSE Was 6734664 - A

7

6667804

COUPLER, FF MALE

7

6669657

SEAL KIT

8

6667803

COUPLER, FF FEMALE

9

6716089

CONNECTOR W/ O-rings

10

6711674

MOUNT

11

84G3712

BOLT 5

12

6718245

TUBE

13

6718244

TUBE

14

HOSE NLA - Order Ref. 15 - Was 6718455 - A

15

6718454

HOSE

15

6718454

HOSE

16

TEE NLA - W/Ref. 21 - tapered boss face - Was 21KV00005B - A

16

97K6

O RING flared end

16

21KB0606

FTG HYD STRAIGHT TEE W/Ref. 21 - flat boss face

16

ELBOW See Illustration HYDROSTATIC CIRCUITRY/ PE1318R NLA - W/REF. 21 - FOR STANDARD FLOW HYD - REF. 52 - TAPERED BOSS FACE - WAS 17KV00005B - A

16

97K6

O RING flared end

16

17KB0606

FITTING See Illustration HYDROSTATIC CIRCUITRY/ PE1318R W/REF. 21 - FOR STANDARD FLOW HYD. - REF. 52 - FLAT BOSS FACE

17

ELBOW NLA - W/Ref. 21 - tapered boss face - Was 17KV00005B - A

17

97K6

O RING flared end

17

17KB0606

FITTING See Illustration HYDROSTATIC CIRCUITRY/ PE1318R W/REF. 21 - FOR STANDARD FLOW HYD. - REF. 52 - FLAT BOSS FACE

18

6718098

CONNECTOR

19

6726192

TUBE

20

6676944

VALVE 90 degree inline check - W/Ref. 21 - check boss face to determine correct replacement O-ring

21

99K10

O'RING tapered boss face

21

79K10

O RING 10 flat boss face

22

6669203

VALVE See Illustration HIGH FLOW HYDRAULICS/ TS1434R - select

23

PUMP See Illustration HYDROSTATIC PUMP/ B17103

24

35C616

BOLT 5

25

99K8

O-RING tapered boss face

26

6726196

HOSE

27

5HM29

HOSECLAMP constant tension - Was 5HM00027B - A

28

1316263

ADAPTER W/Ref. 21 - flat boss face

29

6714904

TEE W/Ref. 30 - check boss face to determine correct replacement O-ring

30

79K16

O RING 10 flat boss face

30

99K16

O-RING tapered boss face

31

ELBOW NLA - W/Ref. 21 - tapered boss face - Was 17KV00007B - A

31

97K10

O-RING 10 flared end

31

17KB1010

FITTING, HYD ELBOW W/Ref. 21 - flat boss face

32

6729094

HOSE Use W/Ref. 33 (NLA/16KN-7 or 16KB01010B Adapter)

32

6705497

HOSE Use W/Ref. 33 (NLA/15KV-7 or 15KB01010B Adapter)

33

ADAPTER NLA - W/Ref. 21 - Use W/Ref. 32 (6729094 Hose) - tapered boss face - Was 16KN00007B - A

33

16KB1010

FITTING, HYD ELBOW W/Ref. 21 - flat boss face

33

ADAPTER NLA - W/Ref. 21 - Use W/Ref. 32 (6705497 Hose) - tapered boss face - Was 15KV00007B - A

33

15KB1010

FITTING, HYD CONNECTOR W/Ref. 21 - flat boss face
