Запчасти Bobcat S-Series DECALS (Inside) ACCESSORIES & OPTIONS

1

6904994

KIT, DECAL

1

7120277AR

KIT, DECAL TRANSLATION

1

7120277BR

KIT, DECAL TRANSLATION

1

7120277JP

KIT, DECAL TRANSLATION

1

7163319AR

KIT, DECAL TRANSLATION

1

7163319BR

KIT, DECAL TRANSLATION

1

7163319CA

KIT, DECAL TRANSLATION Was 7163319JP - D

1

7120273AR

KIT, DECAL TRANSLATION

1

7120276BR

KIT, TRANSLATION S150 PORTUGUESE

1

7152169AR

KIT, TRANSLATION

1

7152169BR

KIT, TRANSLATION

2

6734534

DECAL, SERVICE service checklist & schedule

3

6708929

DECAL, COOLANT propylene glycol

4

6565200

DECAL, FILTER not in kit

5

6709030

DECAL belt tension - spring loaded idler

6

6986651

OHB, W WIRE ROPE not in kit - Was 6902600 - B,D

6

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve

6

6558310

SLEEVE wire rope

6

17C512

BOLT 5

6

84G3112

BOLT 5

7

6727926

DECAL, OPERATION hand & foot controls - not in kit

8

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

9

6734646

DECAL, WARNING selectable joystick controls - not in kit

10

7184776

DECAL, CAPACITY LIFT Was 6725528 - A

11

6735140

DECAL, THROTTLE

12

6734647

DECAL, OPERATION selectable joystick controls - not in kit

13

6728539

DECAL

14

6553976

SAFETY TREAD 127 x 203 mm (5 x 8'')

15

7152748

DECAL, FUEL DIESEL low sulfur

16

7117407

DECAL, FUSE inside fuse cover - 51 x 178 mm (2 x 7'')

16

7159779

DECAL fuse relay - 51 x 178 mm (2 x 7'')
