1
6553411
BUSHING
2
6578278
PAD Was 7156723 - B
3
6598908
ELBOW Was 6553412 - A
4
6624289
STRAP, TIE
5
6701449
FILLER TUBE
6
7203382
PLUG, STEEL Was 6717404 - A
7
6717402
BUSHING
8
6731059
INLET
9
7101291
ELBOW Was 6630041 - A
10
7106279
BOLT
11
7111441
TUBE FUEL LINE
12
7111442
HOSE FUEL LINE
13
HOSE, BREATHER NLA - 800 mm (31.5'') long - Order Ref. 41
14
7162725
TANK, FUEL Was 7111440 - A
15
7169243
BRACKET
16
7179839
SENSOR FUEL See Illustration ELECTRICAL CIRCUITRY/ EM8567
17
7183828
BRACKET, HOLD DOWN Was 7168190 - A
18
26GM10020
BOLT
19
26GM10025
SCREW
20
42HS04
CLAMP, HOSE Was 42HS04 Was 42HS4 - D
21
5HM13
CLAMP
22
5HM24
CLAMP
23
5HM55
CLAMP
24
7115699
BRACKET THROTTLE
25
51DM8
NUT
26
6667170
PUMP
27
6667353
FILTER ASSY W/Ref. 28
28
6667352
FILTER, FUEL W/SEPARATOR 12
29
6715183
ELBOW
30
6733378
SCREW
31
HOSE, FUEL NLA - 420 mm (16.5'') long - Order Ref. 42
32
HOSE, FUEL NLA - 110 mm (4.3'') long - Order Ref. 42
33
HOSE, FUEL NLA - 55 mm (2.165'') long - Order Ref. 42
34
HOSE, FUEL RETURN NLA - 970 mm (38.2'') long - Order Ref. 43
35
HOSE, FUEL NLA - 1220 mm (48'') long - Order Ref. 42
36
1CM816
BOLT
37
29CM820
SCREW
38
5HM14
CLAMP
39
6661114
CAP. DIESEL
39
6661696
CAP, FUEL LOCKING locking - optional
40
7115701
PLATE FUEL FILTER
41
7132913
HOSE, BREATHER bulk - sold per foot Was 6578172 - A
42
6577821
HOSE bulk - sold per foot
43
6578169
HOSE bulk - sold per foot
