Запчасти Bobcat Articulated Loaders REAR DIFFERENTIAL DRIVE TRAIN

1

DRIVE SHAFT See Illustration DRIVE SHAFT/ B13492 See Illustration DRIVE SHAFT/ C3071

2

6646300

NUT

3

6646224

O-RING

4

6646292

FLANGE

5

1GM840

SCREW

6

6646359

COVER

7

6658641

SEAL Was 6646223 - A

8

6646369

NUT

9

6646243

BEARING

10

1CM1035

BOLT

11

6EM100

WASHER

12

6646358

COVER

13

6646355

SHIM .006'' (0,15 mm) Thick

13

6646356

SHIM .008'' (0,20 mm) Thick

13

6646357

SHIM .020'' (0,50 mm) Thick

14

6646363

SPACER 1.654'' (42.02 mm) long

14

6646364

SPACER 1.655'' (42.04 mm) long

14

6646365

SPACER 1.656'' (42.06 mm) long

14

SPACER NLA - 1.657'' (42.08 mm) long - Order 6646364 - Was 6646366 - A

15

6646252

SHIM .014'' (0,35 mm) Thick

15

6646253

SHIM .016'' (0,40 mm) Thick

15

6646254

SHIM .018'' (0,45 mm) Thick

15

6646255

SHIM .022'' (0,55 mm) Thick

16

6646353

GEAR SET Incl. Pinion Gear & Ring Gear

17

6532669

CASE Was 6646350 - A

18

6646303

STUD

19

6EM140

WASHER

20

1DM14

NUT

21

1CM1440

BOLT Was 4CM1440 - A

21

1CM1445

BOLT

22

6646304

PLUG drain

23

6646237

BEARING

24

6646305

CASE

25

20JM1240

DOWEL PIN

26

6646310

WASHER

27

6646313

WASHER

28

6646306

PINION GEAR

29

6646309

SIDE GEAR

30

6646307

SPACER

31

6646308

SHAFT

32

6646270

DOWEL PIN

33

6646312

SHIM

34

6646316

FLANGE

35

6646257

SHIM .008'' (0,20 mm) Thick

35

6646258

SHIM .012'' (0,30 mm) Thick

35

6646259

SHIM .020'' (0,50 mm) Thick

35

6646256

SHIM .006'' (0,15 mm) Thick

36

6646236

BEARING

37

COVER NLA - Order 6532800

37

6532800

COVER Was NLA - D

38

4CM1028

BOLT

39

6646302

PLUG Fill - Metric Threads

39

16F8

PLUG fill - SAE Threads - Was 11F000008B - A

40

1CM1240

BOLT
