Артикул
Название
Примечание
Количество
1
CYLINDER, LIFT See Illustration LIFT CYLINDER/ NA6139
2
CYLINDER, TILT - RH
3
CYLINDER, TILT - LH
4
7216110
VALVE, CONTROL See Illustration HYDRAULIC CONTROL VALVE/ NA6558
5
15KB1010
FITTING, HYD CONNECTOR
6
7109623
ELBOW
7
7153006
HOSE, HYD
8
7153008
HOSE, HYD
9
7162867
HOSE, HYD ASSY
10
7162868
HOSE, HYD ASSY
11
7155829
HOSE, HYD
12
7155830
HOSE, HYD
13
7212038
HOSE, HYD
14
7212037
HOSE, HYD
15
7156319
HOSE, HYD
16
7211820
TUBELINE, HYD
17
7211821
TUBELINE, HYD
18
7204131
VALVE, LEVEL SELF NO Ref. 28, 29, 36-38, 46 & 56-61
19
37C620
BOLT
20
83D6
NUT 5
21
6701892
CLAMP
22
619021
WASHER, 5 0.13'' thick - 32 mm (1.25'') OD
23
84G3728
BOLT
25
7156362
MOUNT, BLKHD
26
46K7
ELBOW
27
46K8
ELBOW
28
86F7
LOCK NUT
29
86F8
NUT 5
30
91K6
TEE
31
91K7
FITTING
32
7152003
HOSE, HYD
33
7152004
HOSE, HYD
34
7152005
HOSE, HYD
35
7168336
HOSE, HYD available only as an assembly W/one danger decal installed near the male threaded end of the hose
35
7170355
DECAL, DANGER
36
7183605
KIT, FITTING W/DECAL W/Ref. 47 - this elbow must always display the danger decal
37
7193758
FITTING, HYD ELBOW
38
7203490
FITTING, HYD CONNECTOR
39
7157358
CLAMP
40
35C616
BOLT 5
41
872229
WASHER 0.19'' thick - 44.5 mm (1.75'') OD
42
7199814
CLAMP, HOSE
43
7199815
CLAMP, HOSE
44
7199946
BOLT
45
35C616
BOLT 5
47
7170355
DECAL, DANGER
48
17C632
BOLT 5
49
7183298
CLAMP
50
7182882
TUBELINE, HYD
51
79K6
O RING 10
52
6684125
COUPLER
53
85D6
NUT, 5
54
6624289
STRAP, TIE
55
84G3740
BOLT
56
30H31
CLAMP 10
57
7203489
FITTING, HYD CONNECTOR
58
7232934
BRACKET, JUNCTION Was 7203491 - C
59
7203506
TUBELINE, HYD
60
88F7
ELBOW
61
86F6
NUT
62
89D6
NUT
63
7199872
SPACER, TUBE
Выбрано товаров: 68
