Артикул
Название
Примечание
Количество
1
6697904
JOYSTICK, LH Ref. 3-6 & 8
2
6697905
JOYSTICK, RH Ref. 3-6 & 8
3
6689922
HANDLE LH - W/Ref. 6
3
6689923
HANDLE RH - W/Ref. 6
4
6689926
BOOT
5
6697939
BASE, JOYSTICK RH
5
6697938
BASE, JOYSTICK LH
6
HARNESS NSS - Order Ref. 3
7
29G416
BOLT
8
6689927
BOLT
9
6737248
DECAL, WARNING selectable joystick control
10
6689020
SWITCH SP ROCKER AWS
11
HANDLE NLA - LH - Order Ref. 17 & 39-43
12
HANDLE NLA - RH - Order Ref. 17, 39-42 & 44
14
25K20100
O RING 10
15
35C512
BOLT
16
89D5
NUT
17
6684294
GROMMET
18
58K120
O-RING Use W/Ref. 25 - Was 6686220 - B,D
19
HARNESS, SJC - NLA - W/Speed sensor connectors - Was 7159456 - A
19
7159456
HARNESS W/O speed sensor connectors
20
6680410
CONTROLLER plastic - W/ 3-connector plug
21
17C616
BOLT 5
22
97D6
NUT 10
23
6679487
CONTROLLER, JOYSTICK DRIVE drive
24
43C616
BOLT
26
69G436
BOLT
27
7108236
PIN
28
MOULDING NLA - 10.5'' (267 mm) long - Order Ref. 30
29
7122359
BRACKET
30
6654139
MOULDING bulk - sold per foot
31
7198706
HARNESS, PUMP Use W/hydrostatic pump Model R902095064 - W/ 3-pin oval connectors - Was 7139761 - A
31
7188448
HARNESS, PUMP Use W/hydrostatic pump Model R902136745 - W/ 3-pin triangle connectors - Was 7169309 - A
31
6664969
CONNECTOR 8-pin
31
6664185
CONNECTOR 2-pin
31
6687268
FEMALE CONNECTOR 3-pin oval - Use W/Ref. 31 (7198706 harness)
31
6664801
CONNECTOR 3-pin triangle - Use W/Ref. 31 (7188448 harness)
31
6691421
FEMALE CONNECTOR grey - 4-pin rectangular
31
6662248
4 PIN PLUG black
32
TIE packaged as 100 pieces
33
6624289
STRAP, TIE
34
6690688
TREE MOUNT
35
6690690
STRAP, TIE
36
30H42
CLAMP
37
7131518
DECAL
38
7131519
DECAL
39
17C612
BOLT 5
40
7124929
BASE
41
6684033
NUT retaining
42
97D6
NUT 10
43
7123817
MOUNT LH
44
7123816
MOUNT RH
45
6691419
CONNECTOR, ELECTRICAL
46
6665370
PLUG
Выбрано товаров: 56
