1
7124301
GUARD hose
2
7124326
RETAINER hose
3
7106279
BOLT
4
6701449
FILLER TUBE ESA
4
7102303
FILLER TUBE domestic only
5
42HL250
CLAMP
6
7186783
HOSE, FUEL Was 7110942 - A
7
5HM24
CLAMP
8
HOSE NLA- 37.25'' (946mm) long - Order Ref. 36
9
6578169
HOSE bulk - sold per foot - 0.19'' ID
10
HOSE NLA - 45.5'' (1156mm) long - Order Ref. 38
11
6735696
GROMMET brown - high temp - .37'' ID
11
6553411
BUSHING 0.38'' ID
12
6717402
BUSHING 0.54'' ID
13
6729854
TUBE 12.5'' (317,5 mm) long
14
5HM13
CLAMP
15
6578278
PAD self adhesive one side
16
7179839
SENSOR FUEL W/Ref. 17 - Was 6680438 - A
17
6717579
GASKET
18
7120881
SCREEN, FILLER Was 6569219 - A
19
6735614
TANK
20
7203382
PLUG, STEEL fuel drain - .75'' shoulder - Was 6717401 - A
20
6599645
PLUG, STEEL .50'' (12,25 mm) shoulder
21
HOSE NLA - 67'' (1702mm) long - Order Ref. 9
22
7171424
MOUNT, FILTER FUEL Was 6731152 - B,D
23
43C516
BOLT
24
6715183
ELBOW W/Ref. 25
25
79K5
O RING 10
26
45C516
SCREW Was 53C516 - A
27
6667353
FILTER ASSY W/Ref. 28
27
6667352
FILTER, FUEL W/SEPARATOR 12
27
72F1
FITTING
28
6658180
PLUG, BLEED
29
HOSE NLA - 13'' (330 mm) Long - Order Ref. 37
30
HOSE NLA - 13.13'' (333 mm) long - Order Ref. 38
31
FUEL PUMP See Illustration FUEL INJECTION SYSTEM/ B27293
32
6657734
PUMP, PRIMER HAND 124 mm (4.88'') long
33
HOSE NLA - 16'' (406mm) Long - Order Ref. 37
34
7101291
ELBOW 3 barb on outlet end
35
84G3712
BOLT 5
36
6578172
HOSE bulk - sold per foot
37
6577822
HOSE bulk - sold per foot - .3125'' ID
38
6577821
HOSE bulk - sold per foot - .25'' ID
39
42HS04
CLAMP, HOSE
40
7025626
VENT, BREATHER - Was 6684923 - A
41
5HM14
CLAMP
42
5HM58
CLAMP
43
30H75
CLAMP
44
6598908
ELBOW
45
6661114
CAP. DIESEL green fuel fill
45
7113340
CAP. DIESEL non-locking - European
46
7121223
CAP. DIESEL LOCKING black
47
6661696
CAP, FUEL LOCKING locking - W/Ref. 48 - Code PK510
48
6587458
KEY Code PK510
49
7023550
CAP, DIESEL LOCKING
50
6693241
KEY 10 ignition - single key W/O ring
