Запчасти Bobcat A-Series COOLING FAN MOTOR (Cast Iron) (S/N 539940001 & Above, 540040001 & Above) HYDROSTATIC SYSTEM

Схема запчастей Bobcat A-Series - COOLING FAN MOTOR (Cast Iron) (S/N 539940001 & Above, 540040001 & Above) HYDROSTATIC SYSTEM

Артикул

Название

Примечание

Количество

1

7164320

MOTOR, HYD COOLING FAN cast iron - Ref. 2-11 - Also Order (2) of 1F316 cotter pin - Was 7132033 - A

2

6698066

HOUSING, FILTER CARTRIDGE

3

6692337

FILTER, HYD CARTRIDGE - cooling fan motor

4

MOTOR NSS - Order Ref. 1

5

6698065

COIL, CPP012H

6

7010979

VALVE, CHECK variable fan speed - W/Ref. 7 - Was 6698064 - A

6

6698591

KIT, SEAL

7

NUT, COIL SOLENOID NLA - Was 6698352 - A

8

6698062

GASKET, MOTOR

9

7000973

PLUG, MOTOR

10

7000974

PLUG, MOTOR

11

6674316

SWITCH, PRESS OIL HYD 3-pin molded connector

12

KIT, SEAL NSS - Order Ref. 1

Выбрано товаров: 13
