1
38C828
BOLT shoulder
2
1313116
BUSHING
3
6568424
ADAPTER
4
6569498
SPRING ASSY
5
6568425
ADAPTER
6
6587182
SWIVEL PIN
7
6586710
BOLT
8
25E21
WASHER 5
9
6518955
SNAP RING
10
6735709
IDLER
11
6670682
BEARING nylon
12
6730894
BOLT
13
6707699
PIVOT
14
6661377
SEAL
15
6587765
BUSHING, PRESS FIT
16
6707698
WASHER
17
17C872
BOLT
18
6660967
CAP grease
19
BOLT NSS - Order Ref. 58 & 59 - Was 17C816 - B
20
SPINDLE NSS - Order Ref. 58 & 59 - Was 6707654 - B
21
SEAL NSS - Order Ref. 58 & 59 - Was 6665307 - B
22
6713287
PULLEY pump
23
BEARING NSS - Order Ref. 58 & 59 - Was 6661229 - B
24
SHIM NSS - Order Ref. 58 & 59 - Was 6701159 - B
25
6665308
SNAP RING
26
WASHER NSS - Order Ref. 58 & 59 - Was 6707697 - B
27
BOLT 5 NSS - Order Ref. 58 & 59 - Was 17C612 - B
28
38C820
SCREW
29
6655781
BEARING thrust
30
6704820
O-RING
31
6700115
SPRING, TORSION
32
73G656
SCREW
33
6725212
ARM W/Ref. 11
34
6704444
WASHER
35
6660995
GREASE RING
36
6662997
PULLEY, FAN DRIVE IDLER
37
6704443
BUSHING
38
6702474
RETAINER
39
61D6
NUT 5
40
17C832
BOLT hydrostatic pump mount
41
85D8
NUT, 5
42
7141328
MOUNT ENGINE See Illustration ENGINE & ATTACHING PARTS/ PE1669 Was 6735980 - A
43
6719828
BOLT
44
14J3112
PIN
45
6576033
WASHER
46
6701160
CLIP
47
7100859
FLYWHEEL ASSY w/ring gear - Was 6730220 - A
47
6665222
GEAR, RING STARTER
48
SHIELD NLA - Order 7109579 shield, also order 7130536 bracket
48
7141330
SHIELD DRIVE has webbed center - Was 7109579 - A
49
6680747
BOLT, FLYWHEEL
50
6662855
BELT, DRIVE pump drive
51
ENGINE See Illustration ENGINE & UPPER GASKET KIT/ B26844 See Illustration ENGINE & UPPER GASKET KIT/ B26841
52
6729944
STOP idler
53
31C820
BOLT
54
6708445
PULLEY drive idler
55
92D12
NUT
56
PUMP See Illustration HYDROSTATIC PUMP/ B26304
57
DECAL NLA - pulley - do not strike - Was 7122009 - A
58
6691330
BEARING idler
59
95D8
NUT
60
1313116
BUSHING if equipped
61
25E21
WASHER 5 if equipped
