Артикул
Название
Примечание
Количество
1
CYLINDER See Illustration TILT CYLINDER/ PE1520 TILT
2
6682411
ADAPTER W/REF. 22
3
6730077
TEE W/REF. 22
4
7102090
HOSE
5
6729702
CLAMP
6
17C632
BOLT 5
7
30H38
CLIP
8
6729721
HOSE
9
97K8
O-RING flared end
9
97K10
O-RING 10 flared end
10
6729694
TEE
11
7102089
HOSE
12
6728180
TUBELINE
13
6730858
TUBELINE
15
6592506
CLAMP
16
84G3740
BOLT Was 84G003736B - B
17
85D6
NUT, 5
18
6624289
STRAP, TIE
19
6729320
CLAMP
20
84G3732
BOLT Was 84G003728B - A
21
6730857
TUBELINE
22
99K10
O'RING tapered boss face
23
872229
WASHER
24
6730876
TUBELINE tilt
25
6730877
TUBELINE tilt
26
6729604
HOSE W/Ref. 22 - available only as an assembly W/two danger decals installed
26
6809511
DECAL, DANGER
27
6701893
CLAMP
28
ELBOW NLA - W/REF. 22 - tapered boss face - Was 6729357 - A
28
7109623
ELBOW W/Ref. 22 - flat boss face - Was 6817335 - A
29
6734761
TUBELINE lift - Was 6730838 - A
30
CYLINDER See Illustration LIFT CYLINDER/ PE1519 LIFT
31
7102337
HOSE Was 6734649 - A
32
7102336
HOSE Was 6734648 - A
33
VALVE See Illustration HYDRAULIC CONTROL VALVE/ PE1745
34
6730914
TEE W/REF. 22
34
97K12
O'RING flared end
35
6730812
TUBELINE lift - Was 6730837 - A
36
6730836
TUBELINE lift
37
21KB1210
FITTING, HYD TEE W/REF. 22
38
17KB1210
FITTING, HYD ELBOW 90 degree - W/REF. 22
39
VALVE See Illustration BUCKET POSITIONING VALVE/ MS1943 BPV
40
6730810
TUBELINE
Выбрано товаров: 47
