Артикул
Название
Примечание
Количество
1
VALVE See BTI336 - NLA - valve is minus all fittings, relief valves, anti-cavitation valves, solenoid coils & solenoid spools - remove & use existing parts from old valve or order new parts as needed
2
6628571
VALVE ASSY See Illustration BICS CONTROL VALVE/ TS1365
3
6589564
RETAINER
4
6587763
BOOT
5
7202038
BUSHING, ALIGNMENT Also Order 82K019 alignment O-ring - Was 6805102 - A
6
99K6
O RING
7
6814511
SPOOL, LIFT Was 6674808 - A
8
6815152
SPOOL, TILT Was 6674814 - A
9
6588074
SPOOL auxiliary - SEE NOTE
10
BODY NSS
11
6592115
SEAT load check
12
6592117
SPRING, LOAD CHECK
13
79K8
O RING 10
14
6592116
NUT load check
15
6667549
VALVE anti-cavity check - W/Ref. 16-18
17
80K14
BACK-UP WASHER Was 73K000014B - B
18
6677106
O-RING Ref. 17 not required
19
6679757
VALVE port relief - W/Ref. 16-18 - 4000 PSI - Was 6671583 - A
20
7219324
VALVE, RELIEF W/ O-rings - pressure to be set in field - Was 6686360 - A
21
58K017
O-RING 10
22
6665569
WASHER back-up
23
25K20016
O RING 10
24
6665570
RING glide
25
6595663
BUSHING
26
7211397
WASHER, SPRING Was 6587523 - A
27
6587580
SPRING
28
6592100
COLLAR
29
6596807
PLUG plastic - 0.46'' long
30
6586918
SCREW
31
6587575
ADAPTER
32
6592107
SPRING
34
6531270
SLEEVE, DETENT
35
6592098
WASHER
36
799119
RING
37
6589226
COVER, END 0.63'' flange
38
6660644
CAP
39
7101345
BONNET, DETENT HYD VALVE Was 6587633 - A
40
30G416
BOLT
41
6592109
ADAPTER
43
6806561
PLUG W/Ref. 73 & 74
44
58K124
O RING 10
45
6596332
SPRING
46
7108780
SLEEVE Was 6595951 - A
47
6592720
PLUG W/Ref. 16-18
48
1K127
O-RING 10 Was 93K127 - A
49
6727931
TEE W/Ref. 6
50
55K204
O RING 10
51
29G444
BOLT
52
29G416
BOLT 1'' long
53
6662848
CAP
54
6805696
TEE W/Ref. 6 - tapered boss face
54
97K6
O RING flared end
55
6806496
TUBELINE
56
6588781
END CAP
57
SOLENOID NLA - Order Ref. 58 & 59 - Was 6677201 - A
58
6676249
STEM, VALVE SOLENOID
58
6679961
NUT coil
58
6586459
SEAL KIT
59
6717706
COIL, 10 VOLT W/ nut - 10 volt - pwm
60
6678552
VALVE port relief & anti-cav. - W/Ref. 16 - 3500 PSI - use in tilt cylinder base end port - Was 6671632 - A
60
6673904
SEAL KIT W/Ref. 16, 67 & 68
61
6816252
SEAL KIT two spool - Ref. 4, 29, 42, 48, 51 & 64 - Was 6806941 - A
61
6816253
KIT, SEAL complete - Ref. 4, 13, 16-18, 21-24, 42, 44, 50-52 & 63- also Order 6816252 seal kit - Was 6809448 - A
61
6632279
KIT, SEAL main relief - Ref. 21-24
61
6809425
SEAL KIT upper deck - Ref. 13 & 16-18
62
6595131
SPRING .72'' OD
63
55K212
O RING 10
64
54K20002
O'RING 10
65
90KV5
PLUG W/Ref. 66
66
95K6
O'RING
67
O-RING NSS - kit - Order Ref. 60
68
O-RING NSS - kit - Order Ref. 60
69
6812031
BLOCK lift and tilt lock - Was 6805657 - A
70
90K8
PLUG W/Ref. 71 - Was 90KV00008B - A
71
95K12
O-RING
72
6805651
BLOCK aux lock - W/Ref. 73 & 74
73
79K7
O RING 10
74
25K20012
O RING 10
Выбрано товаров: 83
