Запчасти Bobcat 800s HYDROSTATIC CIRCUITRY (S/N 5141 12410-14999 & 5142 12270-12999) HYDROSTATIC SYSTEM

1

6707922

BAND

2

6559447

WASHER square

3

84G3716

SCREW 5

4

6727475

CAP, OIL HYD breather - Also Order Ref. 6 - Was 6577785 - A

5

6665915

GAUGE sight

6

6700631

GASKET

7

743108

FITTING W/Ref. 13 - flat boss face

7

CONNECTOR NLA - W/Ref. 13 - tapered boss face - Was 6715649 - A

7

97K6

O RING flared end

7

15KB0608

FITTING, HYD CONNECTOR W/Ref. 13 - flat boss face

8

18K5

ELBOW W/Ref. 13 - flat boss face

8

18KB0606

FITTING, HYD ELBOW W/Ref. 13 - tapered boss face - Was 18KV00005B - A

8

97K6

O RING flared end

9

7120881

SCREEN, FILLER Was 6569219 - A

10

6708560

HOSE

11

21K5

TEE W/Ref. 13 - flat boss face

11

21KB0606

FTG HYD STRAIGHT TEE W/Ref. 13 - tapered boss face - Was 21KV00005B - A

11

97K6

O RING flared end

12

TANK See BTI315 - NLA - Order 6725423 tank & 6727175 tee - Was 6707639 - A

13

79K6

O RING 10 flat boss face

13

99K6

O RING tapered boss face

13

79K8

O RING 10 flat boss face

14

15K5

FITTING W/Ref. 13 - flat boss face

14

ADAPTER NLA - W/Ref. 13 - tapered boss face - Was 15KV00005B - A

14

97K6

O RING flared end

14

15KB0606

FITTING, HYD CONNECTOR W/Ref. 13 - flat boss face

15

44H20

CLAMP worm gear - Was 6666864 - A

15

5HM35

HOSECLAMP constant tension

16

6708474

HOSE

17

6661022

FILTER, OIL HYD IN-LINE See Illustration HYDROSTATIC OIL FILTER/ B13527 - 90 micron

18

MOTOR See Illustration HYDROSTATIC MOTOR/ B18514

19

55K21

O RING 10 Was 58K000021B - B

20

6665206

ELBOW 1.31'' thread - W/Ref. 19 & 48 (75K16 O-ring)

20

7231894

FITTING, HYD ELBOW 1.06'' thread - W/Ref. 19 & 48 (75K12 O-ring)

21

79K16

O RING 10

22

6714545

HOSE Was 6708556 - A

23

6706795

HOSE

24

14K5

TEE

25

6707921

BRACKET

26

47K10

PLUG W/Ref. 21 - for flushing hole in tank

27

6578327

HOSE

28

79K12

O RING 10 flat boss face

28

99K12

O RING tapered boss face

29

1309919

CONECTOR W/Ref. 28

30

6706487

TEE W/Ref. 36

31

61D6

NUT 5

32

35C512

BOLT

33

79K20

O RING 10

34

6706517

SCREW

35

42HL250

CLAMP Was 6513595 - B

36

INLET See BTI412 - NLA - Was 6706354 - A

37

6578812

ADAPTER W/Ref. 28 - flat boss face

37

ADAPTER NLA - W/Ref. 28 - tapered boss face - Was 6715186 - A

37

97K6

O RING flared end

37

15KB0612

FITTING, HYD CONNECTOR W/Ref. 28 - flat boss face

38

36K5

CAP

39

42H24

CLAMP-5 worm gear

39

5HM42

HOSECLAMP constant tension

40

6706445

HOSE

41

44H24

CLAMP worm gear - Was 6667341 - A

41

6672281

CLAMP constant tension - Was 5HM00042B - B

42

6708473

HOSE

43

6706772

TEE W/Ref. 21

44

PUMP See Illustration HYDROSTATIC PUMP/ C3379

45

41E1616

ADAPTER W/Ref. 19 & 48

46

61D5

NUT

47

6712817

TUBE

48

75K16

O RING 10 1.31'' ID

48

75K12

O'RING 10 1.06'' ID
