Запчасти Bobcat 800s DECALS ACCESSORIES & OPTIONS

1

6701898

KIT See Illustration DECALS/ B20243 DECAL - REF. 2 - 14 ON THIS PAGE & REF. 2 - 13

2

6708154

HANDBOOK, OPERATOR'S W/WIRE ROPE Was 6701899 - A

2

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve - Was 6558305 - A

2

6558310

SLEEVE wire rope

3

6703723

DECAL operating - Was 6702553 - A

4

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

5

6702301

DECAL, DANGER Was 6579509 - A

6

6561383

DECAL, OPERATION 5 Bob-Tach locking levers

7

6579510

DECAL warning

8

6579528

DECAL, WARNING carry load low

9

6577947

SAFETY TREAD 190,5 x 381 mm (7.5 x 15'')

10

6702302

DECAL, DANGER Was 6579639 - A

11

6561376

DECAL capacity

12

6735140

DECAL, THROTTLE Was 6557565 - A

13

6577949

SAFETY TREAD 6.8'' x 8.75'' - (172,7 mm x 222,3 mm)

14

6705720

DECAL warning - lock shield

15

6702855

DECAL model no. 853 L.H. - Not in Kit - Was 6579965 - A

15

6703292

DECAL model no. 853H L.H. - Not in Kit

16

6705088

DECAL America's Best - Not in Kit
