SINGLE POINT LIFT (19999 & Below)

Запчасти Bobcat 800s SINGLE POINT LIFT (19999 & Below) ACCESSORIES & OPTIONS

Схема запчастей Bobcat 800s - SINGLE POINT LIFT (19999 & Below) ACCESSORIES & OPTIONS
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

KIT See Illustration SINGLE POINT LIFT KIT/ D1698 NLA - Ref. 2-13 - Order 6568042 Kit

2

17C824

BOLT 5

3

85D8

NUT, 5

4

17C816

BOLT

5

6563494

SHIM

6

6553709

WASHER

7

6560900

RETAINER

8

672401

BOLT

9

6563495

WASHER

10

6560175

ANGLE

11

6563551

WASHER

12

6565932

DECAL safety

13

INSTRUCTIONS NLA - Print Instructions from BASS - Was 6556604 - A
