Запчасти Bobcat 800s DECALS ACCESSORIES & OPTIONS

Схема запчастей Bobcat 800s - DECALS ACCESSORIES & OPTIONS

Артикул

Название

Примечание

Количество

1

6569282

KIT Decal - Ref. 2-17 & 2-12 on Ill B18388

2

6567795

HANDBOOK, OPERATOR'S W/WIRE ROPE

2

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve - Was 6558305 - A

2

6558310

SLEEVE

3

6553976

SAFETY TREAD 127 x 203 mm (5 x 8'')

4

6559077

SAFETY TREAD 3.25'' x 3.25'' (82,5 x 82,5 mm)

5

6565990

DECAL, OIL HYD 5 hydrostatic fluid fill

6

6579509

DECAL danger - Was 6702301 - A

7

6579528

DECAL, WARNING carry load low - Was 6565254 - A

8

6577949

SAFETY TREAD 6.8''(172,7 mm) x 8.75''(222 mm) - Was 6553977 - A

9

6561383

DECAL, OPERATION 5 Bob-Tach locking levers

10

6553978

SAFETY TREAD 35'' x 8'' (889 x 203,2 mm)

11

6702255

DECAL warning

12

6561376

DECAL capacity

13

6565927

DECAL pre-heat

14

6735140

DECAL, THROTTLE Was 6557565 - A

15

6569021

DECAL operating

16

6579510

DECAL warning - Was 6575854 - A

17

6710358

DECAL warning

Выбрано товаров: 19
