Запчасти Bobcat 700s DECALS ACCESSORIES & OPTIONS
№
Артикул
Название
Примечание
Количество
1
6900502
KIT decal
1
6716212AR
KIT decal - SEE NOTE - Was 6716206 AR - B,D
1
6716212BR
KIT decal - SEE NOTE - Was 6716206BR - B,D
1
6716212JP
KIT decal - SEE NOTE - Was 6716210 JP - D
1
6716213AR
KIT translation - SEE NOTE - Was 6716207 AR - B,D
1
6716213BR
KIT translation - SEE NOTE - Was 6716207BR - B,D
2
6708154
HANDBOOK, OPERATOR'S W/WIRE ROPE Was 6704831 - B
2
6708154ES
KIT handbook- W/Wire Rope- Spanish
2
6558309
WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve
2
6558310
SLEEVE wire rope
2
17C512
BOLT 5
2
61D5
NUT
3
6703723
DECAL operating
4
6554100
TREAD 76,2 x 152,4 mm (3 x 6'')
5
6579639
DECAL danger
6
6561383
DECAL, OPERATION 5 Bob-Tach locking levers
7
6579510
DECAL warning
8
6579528
DECAL, WARNING carry load low
9
6577947
SAFETY TREAD 190,5 x 381 mm (7.5 x 15'')
10
6579509
DECAL danger
11
7184776
DECAL, CAPACITY LIFT Was 6725528 - A
12
6735140
DECAL, THROTTLE Was 6557565 - A
13
6707523
SAFETY TREAD LH - 6.8'' x 8.75'' (172,7 mm x 222,3 mm)
13
6707524
SAFETY TREAD RH - 6.8'' x 8.75'' (172,7 mm x 222,3 mm)
14
6707255
DECAL NLA - seat bar operating - W/seat sensor - D
14
6727926
DECAL, OPERATION hand & foot controls - not in kit - Was 6718703 - A
14
6717639
DECAL seat bar operating - W/O seat sensor - AHC
15
6705088
DECAL America's Best
16
6706809
DECAL lift lock
16
6711840
DECAL lift lock
17
6708203
DECAL model no. - 763 - L.H.
17
6709814
DECAL model no. - 763H - L.H. - Not in Kit
18
6708105
DECAL pre heat - Was 6705712 - A
19
DECAL NLA - Ingersoll Rand - Was 6727310 - A
20
6710358
DECAL warning
21
6714533
DECAL model
22
6727913
DECAL high flow - Not in Kit - Was 6714534 - A
23
6715912
DECAL 40th anniversary
24
6710746
SAFETY TREAD 1.25''x15''(31,8mm x 381mm)
24
6727917
SAFETY TREAD 32 x 267 mm (1.25 x 10.5'')
25
6717343
DECAL, DANGER
26
6718275
DECAL Bobcat advantage
27
6718271
DECAL advantage series - L.H. - Not in Kit
Выбрано товаров: 43
