Запчасти Bobcat 700s DECALS ACCESSORIES & OPTIONS

1

6701897

KIT See Illustration DECALS/ B17576 DECAL - REF. 2-16 ON THIS PAGE & REF. 2-15

2

6704831

KIT handbook - W/Wire Rope

2

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve

2

6558310

SLEEVE wire rope

3

6703723

DECAL operating

4

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

5

6579639

DECAL danger

6

6561383

DECAL, OPERATION 5 Bob-Tach locking levers

7

6579510

DECAL warning

8

6579528

DECAL, WARNING carry load low

9

6577947

SAFETY TREAD 190,5 x 381 mm (7.5 x 15'')

10

6579509

DECAL danger

11

7184776

DECAL, CAPACITY LIFT Was 6725528 - A

12

6735140

DECAL, THROTTLE Was 6557565 - A

13

6707523

SAFETY TREAD LH - 6.8'' x 8.75'' (172,7 mm x 222,3 mm) - Was 6577949 - B,D

13

6707524

SAFETY TREAD RH - 6.8'' x 8.75'' (172,7 mm x 222,3 mm) - Was 6577949 - A

14

6705720

DECAL lock shield

15

6705088

DECAL America's Best

16

6710358

DECAL warning

17

6708105

DECAL pre heat - Was 6705712 - A

18

6707481

DECAL capacity - 1600 lbs.

19

6706852

DECAL model no. - 753L - L.H. - Not in Kit

20

6711840

DECAL lift lock

21

6710746

SAFETY TREAD 1.25 in. x 15 in. (31,8 mm x 381 mm)

21

6727917

SAFETY TREAD 32 x 267 mm (1.25 x 10.5'')
