Артикул
Название
Примечание
Количество
1
PUMP, HYD TANDEM NLA - Model 4355066 - complete W/gear pump - gray - Order Ref. 29-32 & 54 - must use 6576196 bracket & 6706096 bracket from original pump - Was 6669464 - A
1
6669464REM
PUMP, HYD TANDEM, W/O GEAR PUMP gray - must use 6576196 bracket & 6706096 bracket from original pump - Was 6671019REM - A
1
PUMP NLA - Model 4355065 - complete W/gear pump - black - export - Order 6669464REM pump - Was 6669465 - A
1
PUMP NLA - Order 6669464REM pump - Was 6669465REM - A
1
PUMP, HYD TANDEM NLA - Model 4445050 - W/aluminum gear pump - Order 6672051REM pump - must use 6576196 bracket & 6706096 bracket from original pump - Was 6672051 - A
1
6672051REM
PUMP, HYD TANDEM, W/O GEAR PUMP
2
6657028
O-RING
3
79K8
O RING 10
4
PLUG NLA - Order Ref. 52 or 53
5
RELIEF VALVE NLA - Order Ref. 53 - 5000 PSI (345 bar) for Pump
6
6645086
PLUG
7
6657067
COVER
8
6650637
BOLT
9
RETAINER NLA - Order Ref. 52 or 53
10
CHECK VALVE NLA - Order Ref. 52 - poppet
11
6669405
CAP, END
12
6650634
GASKET
13
6669400
VALVE PLATE Model 4355066 & 4355065
13
See BTI361 NLA - Model 4445050 - Was 6675339 - A
14
6650636
PIN
15
RETAINER NLA - Order Ref. 26
16
WASHER NLA - Order Ref. 26
17
SPRING NLA - Order Ref. 26
18
WASHER NLA - Order Ref. 26
19
BLOCK NLA - Order Ref. 26
20
6650630
RETAINER
21
6650629
PIN
22
6666338
WASHER
23
RETAINER NLA - Order Ref. 26
24
RETAINER NLA - Order Ref. 26
25
PISTON ASSY. NLA - Order Ref. 26
26
6661758
BLOCK ASSY Models 4355066 & 4355065
26
6671512
GROUP, ROTARY Model 4445050
27
6650627
PLATE
28
6669404
SWASH PLATE Model 4355066 & 4355065
28
6685344
SWASHPLATE W/threaded shaft hole - Was 6671513 - A
29
GEAR PUMP See Illustration GEAR PUMP (MODELS B5501-34727 & B5501-36006)/ TS1035 FOR PUMP MODEL 4355066 & 4355065
29
GEAR PUMP See Illustration GEAR PUMP/ TS1022 FOR PUMP MODELS 4445050
30
6666339
BOLT
31
6645080
O-RING
32
6650677
COUPLER Model 4355066 & 4355065
32
6671509
COUPLER Model 4445050 - Was 6671519 - D
33
669863
RING, SNAP
34
658128
RING, SNAP
35
654299
BEARING
36
6652018
BOLT
37
6669407
SHAFT
38
47K8
PLUG W/Ref. 51
39
6650668
BOLT
40
6657068
COVER
41
6660814
O-RING
42
6669411
BEARING
43
6518460
PIN
44
6669403
HOUSING
45
6576196
MOUNT
46
1CM820
BOLT
47
6650635
BEARING
48
PLUG
49
SPRING NLA - Order Ref. 52 or 53
52
6670684
CHECK VALVE
53
6670685
RELIEF VALVE Models 4355066 & 4355065 - Was 6689601 - A
53
6671510
RELIEF VALVE Model 4445050
54
7001070
PUMP, HYD
55
6658092
SEAL KIT See Illustration HYDROSTATIC PUMP/ D2377 REF. 2, 3, 12 & 41 - ALSO INCLUDES 7, 9, 13, 34, 35, 42, 43, 45 & 46 FOR PUMP MODELS 4355066 & 4355065
55
6671516
KIT, SEAL See Illustration HYDROSTATIC PUMP/ D2377 REF. 7, 9, 13, 34, 35, 42, 43, 45, 46, 50, 57 & 60 - ALSO INCLUDES REF. 2, 3, 12, 31, 41 & 50 FOR PUMP MODEL 4445050
Выбрано товаров: 67
