Запчасти Bobcat 700s DECALS ACCESSORIES & OPTIONS

1

6569281

KIT See Illustration DECALS/ B20277 DECAL - REF. 2-8, 11-18 & REF. 2-6, 8-10, 17

2

6579510

DECAL warning

3

6569021

DECAL operating

4

6561383

DECAL, OPERATION 5 Bob-Tach locking levers

5

6565990

DECAL, OIL HYD 5 hydrostatic fluid fill

6

6735140

DECAL, THROTTLE Was 6557565 - A

7

6561377

DECAL capacity

8

6557413

DECAL LH - Bobcat head

8

6557412

DECAL RH - Bobcat head

9

6710358

DECAL warning

10

6702804

DECAL model no. - L.H. - Not in Decal Kit - shown

10

6702803

DECAL model no. - R.H. - Not in Decal Kit - not shown - Was 6702003 - A

11

6553976

SAFETY TREAD 127 x 203 mm (5 x 8'')

11

6577949

SAFETY TREAD 6.8'' x 8.75'' - Was 6553977 - A

11

6553978

SAFETY TREAD 35'' x 8''

11

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

12

6702255

DECAL Bobcat Logo

13

6579528

DECAL, WARNING carry load low - Was 6565254 - A

14

6567795

HANDBOOK, OPERATOR'S W/WIRE ROPE

14

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve - Was 6558305 - A

14

6558310

SLEEVE wire rope

15

6702302

DECAL, DANGER

16

6565927

DECAL preheat

17

6702301

DECAL, DANGER

18

6710358

DECAL warning
