Запчасти Bobcat 500s DECALS ACCESSORIES & OPTIONS

Схема запчастей Bobcat 500s - DECALS ACCESSORIES & OPTIONS

Артикул

Название

Примечание

Количество

1

6578816

KIT See Illustration DECALS/ C2597 decal - Ref. 2-11 & on this page Ref. 2-15

2

6567795

HANDBOOK, OPERATOR'S W/WIRE ROPE

2

6558309

WIRE ROPE bulk - sold per foot - Also Order (2) of 6558310 sleeve - Was 6558305 - A

2

6558310

SLEEVE

3

6553976

SAFETY TREAD 127 x 203 mm (5 x 8'')

4

6554100

TREAD 76,2 x 152,4 mm (3 x 6'')

5

6565990

DECAL, OIL HYD 5 hydrostatic fluid fill

6

6579509

DECAL danger

7

6579528

DECAL, WARNING carry load low - Was 6565254 - A

8

6577949

SAFETY TREAD 6.8''(172,7 mm) x 8.75''(222,3 mm) - Was 6553977 - A

9

6561383

DECAL, OPERATION 5 Bob-Tach locking levers

10

6553978

SAFETY TREAD 35''(889 mm) x 8''(203 mm)

11

6579639

DECAL danger - Was 6575694 - A

12

6702255

DECAL warning

13

6735140

DECAL, THROTTLE Was 6557565 - A

14

6557569

DECAL capacity

15

6710358

DECAL Warning

Выбрано товаров: 17
