Запчасти Bobcat 400s EUROPEAN ACCESSORIES (Road Kit) ACCESSORIES & OPTIONS

1

KIT See Illustration EUROPEAN ACCESSORIES/ PE1456 SALES - road - Ref. 2 - 25 & Ref. 2 - 27 on Ill. PE1456

2

6668742

SWITCH travel control

3

6668815

SWITCH hazard

4

6668816

SWITCH beacon

5

6675523

BEACON beacon

6

6671106

HORN

7

84G3710

SCREW

8

6731998

BRACKET pin holder

9

6731999

BRACKET boom lock

10

6732000

BRACKET bucket lock

11

1306637

CLIP Was 6512664 - D

12

2F6106

PIN

13

6665860

KIT assy

14

SCREW NLA - Was 85G003712B - A

15

85G616

SCREW 10

16

17E6

WASHER 10

17

6734057

GUIDE SWITCH switch - Was 6707720 - B

18

6646781

SWITCH roller

19

25G510

BOLT

20

6733290

BRACKET

21

55D5

NUT

22

6702593

SPACER

23

6734224

HARNESS BRAKE LT Was 6733734 - B

24

6610510

TIE

25

6901662

INSTRUCTIONS
