Запчасти Bobcat 300s UPPER JACKSHAFT (S/N 14296 & Below) DRIVE TRAIN

1

17C816

BOLT

2

6558268

WASHER

3

57D6

NUT 5

4

6519052

SEAL See Note

5

6511646

BEARING ASSY. See Note

6

6540005

PLATE See Note

7

6500758

GASKET

8

17C624

BOLT 5

9

5J806

KEY

10

6555495

JACKSHAFT See BTI148 Upper

11

SPROCKET NLA - Was 6504461 - A

12

KEY NLA - Was 7J3202 - A

13

PULLEY NLA - driven - Was 6558186 - A

14

6540007

SPACER See Note

15

6555918

SHIM

15

662249

SHIM

16

BEARING ASSY NLA - Order Ref. 20 - Was 6552211 - A

17

6555499

BUSHING

18

6552182

SPACER

19

6552181

SPACER

20

6671906

BEARING insert into Ref. 16 flange
