Запчасти Bobcat BL570 HYDRAULIC CIRCUITRY Frame HYDRAULIC SYSTEM
№
Артикул
Название
Примечание
Количество
1
FITTING NLA
2
6969383
SEAL
3
6966813
FITTING Ref. 1 & 2
4
FITTING NLA
5
6969370
SEAL
6
6966070
FITTING Ref. 4 & 5
7
6966134
HOSE
8
6966138
HOSE
9
6966137
HOSE
10
6966136
HOSE
11
6966135
HOSE
12
FITTING NLA
13
6962101
SEAL
14
6966048
FITTING Ref. 12 & 13
15
6962099
WASHER
16
6966199
HOLDER
17
6966101
NUT
18
6966100
FITTING
19
6961762
VALVE
Выбрано товаров: 19
