Запчасти Bobcat BL370 HYDRAULIC CIRCUITRY (Frame) HYDRAULIC SYSTEM

Схема запчастей Bobcat BL370 - HYDRAULIC CIRCUITRY (Frame) HYDRAULIC SYSTEM

Артикул

Название

Примечание

Количество

1

6965843

STEERING COLUMN steering

2

6962273

STEERING UNIT

3

VALVE NLA - Order 6961784 - Was 6961795 - A

4

FITTING NLA

5

6969371

SEAL

6

6966079

FITTING Ref. 4, 5

7

FITTING NLA

8

17KB1616

FITTING, HYD ELBOW Ref. 26, 27

9

6966073

FITTING Ref. 5, 7

10

HOSE NLA - Print Instructions from BASS - Was 6966139 - A

11

6968812

HOSE

12

1CM1025

BOLT

13

6EM10

WASHER

14

FITTING NLA

15

6969370

SEAL

16

6966070

FITTING Ref. 14, 15

17

6974625

HOSE

18

6974626

HOSE

19

6960885

BRACE

20

6967850

FITTING

21

FITTING NLA

22

6969385

RING

23

6969373

O RING

24

6966088

FITTING Ref. 21, 22, 23

25

6974624

HYDRAULIC CONNECTOR

26

BRACE NLA

27

79K16

O RING 10

Выбрано товаров: 27
