Запчасти Bobcat BL275 HYDRAULIC CIRCUITRY Frame HYDRAULIC SYSTEM

1

6961300

PUMP SET

2

6962789

WASHER

3

6966071

FITTING Ref. 16, 20

4

6966070

FITTING Ref. 17, 21

5

6966046

FITTING

6

6969372

SEAL Was 6966047 - A

7

6966052

FITTING Ref. 18, 22

8

6966053

FITTING Ref. 19, 23

9

6659296

VALVE

10

6966051

VALVE

11

1GM650

BOLT

12

16DM6

NUT

13

6965985

HOSE

14

6965984

HOSE

15

6965983

HOSE

16

FITTING NLA

17

FITTING NLA

18

FITTING NLA

19

FITTING NLA

20

6969372

SEAL

21

6969370

SEAL

22

6969376

O-RING
