Запчасти Bobcat B250 HYDRAULIC CIRCUITRY HYDRAULIC SYSTEM

1

6964674

MOTOR HYDRAULIC

2

6967209

BOLT

3

COVER NLA - End

4

PIN NLA

5

SPRING NLA

6

O RING NLA

7

SCREW NLA

8

SEAL NLA

9

COMMUTATOR NLA

10

SEAL NLA

11

COMMUTATOR NLA

12

6683216

MANIFOLD

13

ROTOR NLA

14

ROTOR NLA

15

ROTOR NLA

16

6683215

PLATE

17

6683212

LINK DRIVE

18

6514056

BEARING Was 6683214 - A

19

6683209

SHAFT

20

6683219

KEY

21

RING NLA

22

WASHER NLA

23

BEARING NLA

24

SEAL NLA

25

SEAL NLA

26

SEAL NLA

27

HOUSING NLA

28

RING NLA

29

SEAL NLA

30

6967210

COVER Ref. 3 - 7

31

6649254

COMMUTATOR Ref. 9, 11 - Was 6683217 - A

32

6683211

ROTOR Ref. 13, 14, 15

33

6683213

SEAL KIT Ref. 8, 10, 24, 25, 26, 29

34

6683208

HOUSING assy - Ref. 21 - 29
