Запчасти Bobcat B100 HYDRAULIC CIRCUITRY Frame HYDRAULIC SYSTEM

1

6960217

PUMP SET

2

1CM1440

BOLT

3

6966071

FITTING ref 10,11

4

6966072

FITTING ref 12,13,14

5

6966073

FITTING ref 15,16

6

6966081

FITTING ref 17,18,19

7

6966929

HOSE

8

6962810

WASHER

9

8EM140

WASHER

10

FITTING NSS

11

SEAL NSS

12

FITTING NSS

13

SEAL NSS

14

O-RING NSS

15

FITTING NSS

16

SEAL NSS

17

FITTING NSS

18

SEAL NSS

19

O-RING NSS

20

6967292

CAP
