Запчасти Bobcat TREE SPADE TREE SPADE (Control Valve) (Used with Convertible Control - Switch box or 7 Pin) (4 Blade) (TS44C 9744) (TS44M 9745) Loader

1

6679465

VALVE ASSY W/Ref. 2 - 6

2

SPOOL, VALVE NLA - W/O screen - Order 6679738 spool

2

6679738

SPOOL W/screen

2

6676635

COIL, SOLENOID

2

6676637

SEAL KIT

2

SCREEN, SOLENOID NLA - For NLA/ spool W/O screen - Order 6679738 spool - Was 6678319 - A

3

SPOOL, VALVE NLA - W/O screen - Order 6679739 spool

3

7024999

SPOOL, VALVE W/screen - Was 6679739 - A

3

7021363

COIL, SOLENOID Was 6676636 - A

3

6678321

SEAL KIT

3

SCREEN, SOLENOID NLA - For NLA/ spool W/O screen - Order 6679739 spool - Was 6678320 - A

4

6679742

COIL

4

6679741

SPOOL

4

6680524

SEAL KIT

4

6679743

NUT retaining

5

6676635

COIL, SOLENOID

5

6679740

SPOOL

5

6680525

SEAL KIT

6

6678322

ORIFICE

7

6729943

HARNESS 7-pin

8

6732431

SWITCHBOX ASSY See Illustration TREE SPADE/ PE2407 PENDANT CONTROL - WITH REF. 9

9

6732434

HARNESS harness only

10

6732249

HARNESS controller to valve

11

6678675

CONTROLLER, ACD
