Запчасти Bobcat SPRAYER SPRAYER 3PT (Roller Pump) (ABKT) Компактные тракторы

1

7002783

PUMP, SPRAYER PTO W/Ref. 2 - 10

2

PLATE, END C6500D order Ref 1 - Was 7002786

3

7002787

BEARING, BALL

4

7002788

SEAL, SHAFT

5

PLATE, END order Ref 1 - Was 7002789

6

7002790

O-RING

7

7002791

ROLLER, PUMP

8

ROTOR, PUMP SPRAYER order Ref 1 - Was 7002793

9

SHAFT, OUTPUT order Ref 1 - Was 7002794

10

HOUSING, PUMP PTO order Ref 1 - Was 7002795

11

7002778

KIT, REPAIR COUPLER PTO W/Ref. 4, 6 & 7

12

7002777

COUPLER, PTO not included with Ref. 1 pump assy
