Запчасти Bobcat PLANERS PLANER (Hydraulics) (910200102 & Above) Loader

1

1519324

PLUG

2

1513549

CAP

3

6648967

QUICK COUPLER female - poppet

3

6667803

COUPLER, FF FEMALE

4

6648969

QUICK COUPLER male - poppet

4

6667804

COUPLER, FF MALE

4

6669657

SEAL KIT

5

79K6

O RING 10

6

17K5

ELBOW

7

6667383

HOSE

8

77F5

FITTING

9

6667548

HOSE

10

6666904

TUBELINE

11

6666905

TUBELINE

12

6666658

TUBELINE

13

6666659

TUBELINE

14

6666657

TUBELINE

15

6661766

REGULATOR 4 GPM

16

6659993

O-RING

17

VALVE See Illustration PLANER/ B25259

18

CYLINDER See Illustration PLANER/ B12574

19

17KB0606

FITTING Was 6657211 - A

20

6558510

ELBOW

21

6667547

TEE

22

36K5

CAP

23

6667681

ADAPTER

24

79K8

O RING 10

25

6589193

ELBOW

26

79K12

O RING 10

27

6666655

TUBELINE

28

6578870

CLAMP

29

17C428

BOLT

30

61D10

NUT

31

6579255

WASHER

32

6666656

TUBELINE Use with older style valve

33

6658487

ELBOW Use with older style valve

34

KIT NLA - Conversion - converts planer with hand crank depth control to hydraulic depth control - Was 6670317 - A

35

1300059

ELBOW
