Запчасти Bobcat GRAPPLES LOG GRAPPLE - 900 Series Loader

1

30K308

ELBOW

2

6509130

CYLINDER See Illustration HYDRAULIC CYLINDER - 900 Series/ B1187 HYDRAULIC

3

15C1672

BOLT

4

17C420

BOLT

5

6502779

PIN hinge - Was 6504064 - A

6

61D4

NUT 5

7

4E16

WASHER

8

61D16

LCKNUT

9

6507416

HOSE

10

6507415

HOSE

11

6507398

TEETH

12

633157

PIN

13

6507418

PIN hinge

14

LEVER NLA - for lock - Order 6665216 - Was 756446B - A

15

654618

PIN

16

6517882

SPRING

17

PIN NLA - fork lock - Order 6680122 - Was 756447B - A

18

6507417

FORK 48'' (1219,2mm)long

19

6515599

CAP W/Chain

20

6515598

PLUG W/Chain

21

6515596

QUICK COUPLER female

21

25K40110

O RING 10

21

73K219

BK UP RG

22

6515597

QUICK COUPLER male

23

19F9

BUSHING

24

6507414

HOSE

25

6507407

MAIN FRAME

26

61D6

NUT 5

27

6502203

CLAMP

28

10K6

FITTING

29

6591810

DECAL pallet fork rating

30

6505023

BEARING self aligning
