Запчасти Bobcat GRADER GRADER (Control Valve) (84 648000101 - 01630) Loader

1

6677501

VALVE ASSY Ref. 2 - 19

2

6678565

VALVE

3

6678566

SEAL KIT

4

6675187

ELEMENT

5

6674283

SEAL KIT

6

6678563

PLUG W/Ref. 20

7

6661443

VALVE 4-way, 3 pos. - W/Ref. 8-12

8

7D8

NUT 5

9

6671026

COIL

10

6679086

VALVE Was 6674445 - D

11

SPOOL NSS

12

6661448

SEAL KIT

13

6673978

CABLE TIE orange

13

6673979

CABLE TIE white

13

6673980

CABLE TIE yellow

13

6673981

CABLE TIE blue

13

6673982

CABLE TIE green

13

6673983

CABLE TIE brown

14

6678567

VALVE BLOCK

15

PLUG NLA - Was 6673833 - A

16

6669620

PLUG

16

O-RING NSS - Order 6669620 Plug

17

6665719

PLUG

17

O-RING NSS - Order 6665719 Plug

18

6669615

ORIFICE 0.02

19

6678564

ORIFICE 0.135

20

O-RING NSS - Order Ref. 6 - Was 95K10 - B,D
