Запчасти Bobcat BACKHOE BACKHOE (Rear Stabilizer) (Quick-Tach) (843 HHH 503750450 & Above) REAR STABILIZERS

1

6660205

SEAL Was 6513483 - A

2

6513482

SWITCH

3

19K7

TEE W/Ref. 4

4

79K10

O RING 10

5

80F7

NUT

6

9K4

ADAPTER

7

6701203

HOSE

8

21K7

TEE W/Ref. 11

9

6578643

HOSE

10

15K3

CONNECTOR W/Ref. 14

11

79K4

O RING 10

12

17C680

BOLT

13

15KB1012

FITTING, HYD CONNECTOR W/Ref. 14 - Was 755055B - A

14

79K12

O RING 10

15

6515589

ELBOW W/Ref. 14

16

VALVE See Illustration BACKHOE/ B20708 diverter

17

45K5

FITTING

18

86F5

NUT

19

1631632

ELBOW

20

2341398

COUPLER male

21

2342026

COUPLING female

21

25K30018

O RING 10

22

83F5

ELBOW

23

6530884

HOSE Was 5207800B - A

24

6560668

PIN

25

23J16

SNAP RING Was 662770B - B

26

CYLINDER See Illustration BACKHOE/ B20608 See Illustration BACKHOE/ B20607

27

6567702

PIN

28

6703819

RETAINER Was 6578760 - A

29

6564692

WASHER

30

17C816

BOLT

31

14J1214

ROLL PIN

32

61D10

NUT

33

6560664

TUBE

34

17C824

BOLT 5

35

85D8

NUT, 5

36

6560678

ANGLE

37

22J16

SNAP RING Was 1320431B - B

38

6560669

PIN

39

6567697

CHANNEL

40

6563438

HOSE

41

6701167

MOUNT

42

17C624

BOLT 5

43

25E18

WASHER

44

85D6

NUT, 5

45

6563437

HOSE

46

6701208

DECAL

47

1513549

CAP

48

1519324

PLUG

49

6567082

BLOCK weld-on

50

6632446

PAD See BTI235 street - weld-on

51

19K5

FITTING W/Ref. 52

52

79K6

O RING 10

53

6720341

INSTRUCTIONS hydraulic kit

53

6566771

INSTRUCTIONS stabilizer

54

6537282

HOSE

55

21K5

TEE

56

6701195

HYD. KIT Ref. 1-7, 9-21, 27, 29, 30, 40, 49 & 53-55

57

31H27

CLIP

58

35C616

BOLT 5
