Запчасти Bobcat BACKHOE BACKHOE (Rear Stabilizer) (Quick-Tach) (843 15001 & Above) REAR STABILIZERS

1

6554858

BALL JOINT

2

8D4

NUT

3

85D6

NUT, 5

4

6564797

WASHER

5

6599643

BEARING Was 6631953 - A

6

85D4

NUT 5

7

6564798

SPACER

8

6567865

FLANGE

9

17C620

BOLT

10

6599469

CABLE

11

6592766

U-BOLT

12

6565006

MOUNT

13

85D5

NUT 5

14

17C416

BOLT

15

6565005

ADAPTER

16

7D4

NUT

17

45K5

FITTING

18

86F5

NUT

19

1631632

ELBOW

20

2341398

COUPLER male

21

2342026

COUPLING female

21

25K30018

O RING 10

22

83F5

ELBOW

23

6530884

HOSE Was 5207800B - A

24

6560668

PIN

25

23J16

SNAP RING Was 662770B - B

26

CYLINDER See Illustration BACKHOE/ B20608 See Illustration BACKHOE/ B20607

27

6567702

PIN

28

6578760

RETAINER Was 6567080 - A

29

6564692

WASHER

30

35C816

BOLT

31

14J1214

ROLL PIN

32

61D10

NUT

33

6560664

TUBE

34

17C824

BOLT 5

35

85D8

NUT, 5

36

6560678

ANGLE

37

22J16

SNAP RING Was 1320431B - B

38

6560669

PIN

39

6567697

CHANNEL

40

6563438

HOSE

41

15K7

FITTING W/Ref. 53

41

731795

CONNECTR W/Ref. 53

42

6567700

TUBE

42

6563438

HOSE

43

6567701

TUBE

43

6563438

HOSE

44

21K5

TEE W/Ref. 49

45

6630527

VALVE

45

6660645

SEAL KIT

46

755051

FITTING W/Ref. 49

46

15K5

FITTING W/Ref. 49

47

6563437

HOSE

48

17C536

BOLT

49

79K6

O RING 10

50

6567013

DECAL

51

1513549

CAP

52

1519324

PLUG

53

79K10

O RING 10

54

8D5

NUT

55

6567082

BLOCK weld on

56

6632446

PAD See BTI235 street - weld on

57

6570123

INSTRUCTIONS W/Ref. 58

57

INSTRUCTIONS NLA - print instructions from bass - Was 6566772 - A

58

KIT NLA - auxiliary control - Ref. 1-16 & 57 - Was 6565749 - A

58

HYD. KIT NLA - Ref. 13, 17-21, 27, 29, 30, 40, 52, 55, 57 & 58 - Was 6567723 - A

58

HYD. KIT NLA - Ref. 13, 17-21, 27, 29, 30, 40, 52, 55, 57 & 58 - Was 6576505 - A
